Heat Resistant Oil Resistant Electrical Cable UL1887
heat resistant oil resistant electrical cable ul1887PRODUCT DESCRIPTION:Rated temperature:150ºCRated voltage:600VAccording to:UL Subject758,UL1581,C22.2Nickel plating or tin/bare copper conductorFEP InsulationPasses UL VW-1&CSA FT1 vertical flame testUniform insulation thickness of wire......
Send Inquiry
Product Description
heat resistant oil resistant electrical cable ul1887
Our products Application Areas:
Product standard
Our products can meet UL, VDE, CCC, PSE certificate requirement and the products are accord with ROHS and REACH Halogen free standard.
Our factory could meet ISO9001:2008 management systems standard. There are 6 production lines in high quality, precise, automation which supporting daily capacity 300,000km cables at least.
Q1: Can I get a free sample?
A1: We can provide the existing items samples free in freight collected. If there is any special samples requirement, please contact us for more details.
Q2: How could I pay?
A2: We prefer T/T or L/C at sight. If you prefer other payment terms, please contact us freely.
Q3: What is your packing way? Can I have the customized package?
A3: We have the standard export package. For more details about the customized package, please contact us.
Q4: What is the delivery lead time?
A4: It depends on the order quantities. The mass production lead time is about 7-12 days after receipt of the deposit.
Q5: Are you a factory or a trading company?
A5: We are a factory. We provide all kinds of OEM/ODM services for clients around the world.
Q6: Where is your main market
A6: We export to the North America, Southeast Asia, Europe, Korea, Japan, and other countries.
Our Services
1. Professional QC and QA team to make sure all products qualified before shipping.
2. Competitive price
3 .Standard package to ensure the safe transportation.
4. Professional service
Why choose us
1. Production
Qualified production, competitive price, professional service.
2. Technology
Professional R& D team
3. Equipment
With completive testing equipment.
4. Quality
UL/ CE/ FCC/ RoHS/ Reach certificate
PRODUCT DESCRIPTION:
Rated temperature:150ºC
Rated voltage:600V
According to:UL Subject758,UL1581,C22.2
Nickel plating or tin/bare copper conductor
FEP Insulation
Passes UL VW-1&CSA FT1 vertical flame test
Uniform insulation thickness of wire to ensure
easy stripping and cutting
For general purpose internal wiring of appliance
| AWG | NO.of Cond (mm) | Conductor resistance 20ºC (Ω/KM) | Conductor Dia (mm) | Insulation Thickness (mm) | Overall Diameter (mm) | ||
| Nom. | Min. | Nom. | Tol. | ||||
| 10 | 37/0.42 | 3.54 | 2.94 | 0.35 | 0.33 | 3.60 | ±0.15 |
| 12 | 37/0.374 | 5.64 | 2.62 | 0.35 | 0.33 | 3.32 | ±0.15 |
| 14 | 19/0.361 | 8.96 | 1.85 | 0.35 | 0.33 | 2.60 | ±0.10 |
| 16 | 19/0.287 | 14.60 | 1.50 | 0.35 | 0.33 | 2.20 | ±0.10 |
| 18 | 19/0.235 | 23.20 | 1.18 | 0.35 | 0.33 | 1.90 | ±0.10 |
| 20 | 19/0.19 | 36.70 | 0.95 | 0.35 | 0.33 | 1.65 | ±0.10 |
| 22 | 19/0.15 | 59.40 | 0.76 | 0.35 | 0.33 | 1.45 | ±0.10 |
| 24 | 7/0.2 | 94.20 | 0.61 | 0.35 | 0.33 | 1.30 | ±0.10 |
| 26 | 7/0.16 | 150.00 | 0.48 | 0.35 | 0.33 | 1.20 | ±0.10 |
| 28 | 1/0.32 | 227.00 | 0.320 | 0.35 | 0.33 | 1.02 | ±0.10 |
| 30 | 1/0.254 | 361.00 | 0.254 | 0.35 | 0.33 | 0.96 | ±0.10 |
Our products Application Areas:
Product standard
| Conductor | Finished product | ||||
| AWG | NO.of Cond | Jacket Thick. | Outside Thick. | ||
| No./mm | mm | mm | |||
| 40 | 7/0.03 | 0.045 | 0.18 | ||
| 40 | 7/0.03 | 0.06 | 0.21 | ||
| 40 | 7/0.03 | 0.06 | 0.21 | ||
| 38 | 7/0.04 | 0.045 | 0.21 | ||
| 38 | 7/0.04 | 0.06 | 0.24 | ||
| 38 | 7/0.04 | 0.06 | 0.24 | ||
| 36 | 7/0.05 | 0.06 | 0.28 | ||
| 36 | 19/0.03 | 0.06 | 0.28 | ||
| 36 | 19/0.03 | 0.06 | 0.28 | ||
| 34 | 7/0.06 | 0.07 | 0.32 | ||
| 34 | 19/0.04 | 0.06 | 0.32 | ||
| 32 | 7/0.08 | 0.07 | 0.38 | ||
| 32 | 19/0.05 | 0.07 | 0.38 | ||
| 30 | 7/0.10 | 0.10 | 0.50 | ||
| 30 | 19/0.06 | 0.10 | 0.50 | ||
| 28 | 7/0.127 | 0.11 | 0.60 | ||
| 28 | 19/0.08 | 0.10 | 0.60 | ||
Our products can meet UL, VDE, CCC, PSE certificate requirement and the products are accord with ROHS and REACH Halogen free standard.
Our factory could meet ISO9001:2008 management systems standard. There are 6 production lines in high quality, precise, automation which supporting daily capacity 300,000km cables at least.
Q1: Can I get a free sample?
A1: We can provide the existing items samples free in freight collected. If there is any special samples requirement, please contact us for more details.
Q2: How could I pay?
A2: We prefer T/T or L/C at sight. If you prefer other payment terms, please contact us freely.
Q3: What is your packing way? Can I have the customized package?
A3: We have the standard export package. For more details about the customized package, please contact us.
Q4: What is the delivery lead time?
A4: It depends on the order quantities. The mass production lead time is about 7-12 days after receipt of the deposit.
Q5: Are you a factory or a trading company?
A5: We are a factory. We provide all kinds of OEM/ODM services for clients around the world.
Q6: Where is your main market
A6: We export to the North America, Southeast Asia, Europe, Korea, Japan, and other countries.
Our Services
1. Professional QC and QA team to make sure all products qualified before shipping.
2. Competitive price
3 .Standard package to ensure the safe transportation.
4. Professional service
Why choose us
1. Production
Qualified production, competitive price, professional service.
2. Technology
Professional R& D team
3. Equipment
With completive testing equipment.
4. Quality
UL/ CE/ FCC/ RoHS/ Reach certificate
